C Series
Rotary Powder Molding Machine

Satisfies with large-scale runs.

Numerous punches have been designed into the C series for the handling of large-scale production runs with one of the largest die table which has 640mm pitch circle diameter.

  • C Series Rotary Powder Molding Machine
  • C Series Rotary Powder Molding Machine
  • C Series Rotary Powder Molding Machine

Product Features

KIKUSUI has remained one step ahead in the powder molding machine industry, which has a constant demand for machinery capable of producing difficult products.
Take for example KIKUSUI's BARPRESS and CAPPRESS series, whose line-ups have been designed to handle odd-shaped items, especially those required in electric, electronic, chemical and food industries.

Not only are KIKUSUI's BARPRESS and CAPPRESS machines suitable for the production of odd-shaped items, but their high-quality output and easy, one touch maintenance gives them the added edge. the machine in both series has been specially designed to handle ferrite, plastics and ceramics, which, with an added variety of options, can easily adapt to even the most specific of needs.

  • ModelBARPRESS correct
    Type2033SM8CY0555DT8CY
    No. of Stations3355
    Type of toolingKey Roll
    Max pressure (kN)Pre 50/Main 200Pre 50/Main 50
    Max tablet dia (mm)1810
    Turret speed (rpm)5-157-20
    Tablets/hr.9,900-29,70046,200-132,000
    Filling depth (mm)0-600-10
    Tablet thickness (mm)5-350-5
    Main Motor (kW)113.7
    Dimension (W*D*Hmm)1,160x1,160x2,1901,060x1,000x1,600
    Weight (kg)7,0002,800
    ModelBARPRESS correct
    Type2033SM8CY0555DT8CY
    No. of Stations3355
    Type of toolingKey Roll
    Max pressure (kN)Pre 50/Main 200Pre 50/Main 50
    Max tablet dia (mm)1810
    Turret speed (rpm)5-157-20
    Tablets/hr.9,900-29,70046,200-132,000
    Filling depth (mm)0-600-10
    Tablet thickness (mm)5-350-5
    Main Motor (kW)113.7
    Dimension (W*D*Hmm)1,160x1,160x2,1901,060x1,000x1,600
    Weight (kg)7,0002,800
